Artillian 3000 Lb. Skid Steer Quick Attach Frame with Pallet Forks

Artillian 3000 Lb. Skid Steer Quick Attach Frame

Pallet Forks with Skid Steer Quick Attach Frame

$1,289.00 – $1,407.00

Forks with 3000 Lb. Skid Steer QA Frame fits any Universal Quick Attach or Skid Steer Quick Attach loader meeting SAE J2513 standard.

Includes built-in 2-inch receiver
ITA Class 2A Hook-Type Fork Tines

*Some Quick Attach Mounts may limit rear passage of ball mount.

Frame & Fork Sets

Clear

SKU: N/A Categories: Quick Attach Frames, Quick Attach Frames & Pallet Forks, Artillian Frames for Skid Steer Quick Attach

Adjustable Fork Spacing – Forks can be spaced from 10 inches (250 mm) to 40 inches (1020 mm) apart and locked in place

Ground Rail Bevels – Match the fork tines for smooth fork sliding, just like forklift carriages

MIG Welded Construction – Engineered for strength and professionally handcrafted

Quality Materials – Built entirely in USA with high-strength North American steel

Durable Protection – Baked on powder coat is augmented by our proprietary graphite coating on the fork rails for the easiest sliding of forks

Chain Slots – For 5/16 inch (8 mm) link chain at all four corners for easy lifting and securing of loads

Finish – Dark Dark gray powder coating to complement any tractor

Trussed Frame – Every pound of excess weight is removed without losing strength

Industry Standard Forks – ITA Class II hook type (fixed) fork tines

Super High-Strength Upper & Lower Fork Rails – No cheap-formed steel. Our frames are built like a real forklift carriage. These rails are laser cut from extremely high-strength and wear-resistant North American steel

Fork frame is designed for a maximum load of 3000 lb. (1360 kg) at 18 inches (46 cm) load center. Maximum load may be limited by lower-capacity fork tines.
